CAT 329 D
Cena bez PVN
Drukāt
INFORMĀCIJA
Produktu grupa
Kāpurķēžu ekskavatori
Zīmols / modelis
CAT 329 D
Ražošanas gads
2023
Darba stundu skaits
588 h
Valsts
Ķīna
Vispārējā pakāpe
1
2
3
4
5
Mascus ID
D88E6053
IZCENOJUMS
Izvēlieties valūtu
PAPILDUS INFORMĀCIJA
Noliktavas Nr.
1
Tips
Dīzeļa
Ražotāja numurs
1
Iepriekšējo īpašnieku skaits
1
Pēdējā tehniskā apskate (datums)
2025-07-15
Ritošās daļas kondicionēšana
Good Condition
Dzinējs
Original
Bruto svars
29 240 kg
Dzinēja jauda
152 kW (207 zirgsp.)
Dzinēja ražotājs
Original
Reģistrācijas numurs
1
Emisijas klase
Fāze V
Kausa ietilpība
1,10 m3
Sliežu platums
600 mm
Papildu hidraulikas izejas parametri
235 l/min
Maksimālais ātrums
5,30 km/h
Transportēšanas izmēri (GxPxA)
10410 x 2990 x 3180 mm
Oriģinālā krāsa
Original
Kausa/ stieņa garums
3 200 mm
Stāvoklis/garantija
1 Year
Ražošanas valsts
Amerikas Savienotās Valstis
Piegādes nosacījumi
FCA, FOB, CIF, EXW
Sertifikāti
EPA, CE
Dažādi piederumi- papildaprīkojums
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET
TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET
CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours:24 hours, holidays and Sundays
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Papildaprīkojums
aizsargvārsts šļūteņu pārraušanas gadījumam (strēle)
aizsargvārsts šļūteņu pārraušanas gadījumam (strēle)
Vīts grozs
Gaisa kondicionētājs
Motora priekšfiltrs
Sijāšanas kauss
Rotējošā bākuguns
Luksuss aprīkojums
Vadības svira
Standarta rakšanas kauss
Kauss ar kabeli
V ditch bucket
Papildinformācija
Specification
The working weight of the entire machine (kg) is 29,240
Bucket capacity (m³)1.1
Boom length (mm) : 6150
The length of the boom (mm) is 3200
Origin: Japan
Tonnage (tons)29
Power Traditional Power
Bucket backhoe
Joint venture/import by manufacturers
Power Traditional Power
Performance
Rotational speed (rpm) : 10.2
Walking speed (km/h) : 3.5/5.3
Climbing ability (%)70/35°
Power system
Engine model: C7ACERT
Rated power (kw/rpm)152/2000
Displacement (L)7.2
Number of cylinders (6
Cylinder diameter × stroke (mm)110×127
The cooling method is water cooling
Hydraulic system
The main overflow set pressure (Mpa) is 3.5
The maximum flow rate of the main pump (l/min) is 235
Working hydraulic circuit (Mpa)3.5
Walking hydraulic circuit (Mpa)3.5
Rotary hydraulic circuit (Mpa)2.75
Pilot oil circuit (MPa)3.9
Boom cylinders - Number × cylinder diameter × stroke (mm)140×1407
Bucket rod cylinder - number × cylinder diameter × stroke (mm)150×1646
Bucket cylinder - Number × cylinder diameter × stroke (mm)135×1156
Is the hydraulic crushing pipeline standard? No
Oil capacity
Fuel tank (L)520
Hydraulic oil tank (L)145
Hydraulic System (L)310(including the oil tank)
Engine oil change volume (L) : 30
Coolant (L)30
Main body size
Total transportation length (mm) : 10410
The total transportation width (mm) is 2990
The total transportation height (mm) is 3180
The total height of the cab (mm) is 3040
The ground clearance of counterweights (mm) is 1110
The grounding length of the track (mm) is 3490
The total length of the tracks (mm) is 4360
Track plate width (mm) : 600
The total width of the tracks (mm) is 2990
Track gauge (mm) : 2390
Minimum ground clearance (mm) : 490
Rear end turning radius (mm) : 3080
Scope of work
The maximum excavation radius (mm) of the shutdown face is 10,600
Maximum excavation depth (mm) : 7170
Maximum excavation height (mm) : 9990
Maximum unloading height (mm) : 7020
Maximum vertical excavation depth (mm) : 6510
Maximum effective excavation depth (mm) : 7010
Width × height (mm) of the bulldozer board without a bulldozer shovel
Lifting or deepening with a bulldozer (mm) without a bulldozer
