INFORMĀCIJA

Produktu grupa
Kāpurķēžu ekskavatori
Zīmols / modelis
CAT 323 D
Ražošanas gads
2023
Darba stundu skaits
520 h
Valsts
Ķīna
Vispārējā pakāpe
1
2
3
4
5
Mascus ID
85540D99

IZCENOJUMS

Izvēlieties valūtu

PAPILDUS INFORMĀCIJA

Noliktavas Nr.
1
Tips
Dīzeļa
Ražotāja numurs
1
Iepriekšējo īpašnieku skaits
1
Pēdējā tehniskā apskate (datums)
2025-07-15
Ritošās daļas kondicionēšana
Good Condition
Dzinējs
Original
Bruto svars
23 100 kg
Dzinēja jauda
110 kW (150 zirgsp.)
Dzinēja ražotājs
Original
Reģistrācijas numurs
1
Emisijas klase
Fāze V
Kausa ietilpība
1,20 m3
Sliežu platums
600 mm
Papildu hidraulikas izejas parametri
205 l/min
Maksimālais ātrums
5,50 km/h
Transportēšanas izmēri (GxPxA)
9460 x 3180 x 3050 mm
Oriģinālā krāsa
Original
Kausa/ stieņa garums
2 900 mm
Stāvoklis/garantija
1 Year
Ražošanas valsts
Amerikas Savienotās Valstis
Piegādes nosacījumi
FCA, FOB, CIF, EXW
Sertifikāti
EPA, CE
Dažādi piederumi- papildaprīkojums
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Papildaprīkojums
aizsargvārsts šļūteņu pārraušanas gadījumam (strēle)
aizsargvārsts šļūteņu pārraušanas gadījumam (strēle)
Vīts grozs
Gaisa kondicionētājs
Rādīt vairāk
Papildinformācija
Specification Power Traditional Power Joint venture/import by manufacturers Bucket backhoe Tonnage (tons)23 The working weight of the entire machine (kg) is 22,300-23,100 Bucket capacity (m³)1.2 Boom length (mm) : 5700 The length of the boom (mm) is 2900 Origin: Japan Performance Rotational speed (rpm) : 11.5 Walking speed (km/h) : 3.5/5.7 Climbing ability (%)70/35° Bucket digging force (kN) : 140 The digging force of the boom (kN) is 106 Power system Engine model: C6.4ACERT Rated power (kw/rpm) : 110/2000 Displacement (L)6.4 Number of cylinders (6 Cylinder diameter × stroke (mm) : 102×130 The cooling method is water cooling Hydraulic system The maximum flow rate of the main pump (l/min) is 205 Pilot oil circuit (MPa)3.9 Working hydraulic circuit (Mpa)3.5 Walking hydraulic circuit (Mpa)3.5 Rotary hydraulic circuit (Mpa)2.5 The main overflow set pressure (Mpa) is 3.5 Boom cylinders - number × cylinder diameter × stroke (mm)120×1260 Bucket rod cylinder - number × cylinder diameter × stroke (mm)140×1504 Bucket cylinder - Number × cylinder diameter × stroke (mm)120×1104 Is the hydraulic crushing pipeline standard? No Oil capacity Fuel tank (L)410 Hydraulic oil tank (L)120 Hydraulic System (L)260(including the oil tank) Engine oil change volume (L) : 30 Coolant (L)25 Main body size The total transportation length (mm) is 9460 The total transportation width (mm) is 3180 The total transportation height (mm) is 3050 The total height of the cab (mm) is 2950 The grounding length of the track (mm) is 3650 The total length of the track (mm) is 4455 Track plate width (mm) : 600 The total width of the tracks (mm) is 3180 Track gauge (mm) : 2380 Minimum ground clearance (mm) : 450 The ground clearance of the counterweight (mm) is 1020 The rear end turning radius (mm) is 2940 Scope of work The maximum excavation radius (mm) of the shutdown face is 9850 Maximum excavation depth (mm) : 6710 Maximum excavation height (mm) : 9470 Maximum unloading height (mm) : 6500 The maximum vertical excavation depth (mm) is 5860 The maximum effective excavation depth (mm) is 6380 Width × height (mm) of the bulldozer board without a bulldozer shovel Lifting or deepening with a bulldozer (mm) without a bulldozer

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 Ķīna
