Sany SY 155 C

# SANY SY155C Crawler Excavator Specifications Model: SANY SY155C Operating Weight: 14100 kg Bucket Capacity: 0.65 m³ Transport Dimensions (L×W×H): 7750 × 2550 × 2880 mm Track Shoe Width: 500 mm Travel Speed (High/Low): 5.5 / 3.5 km/h Swing Speed: 12 rpm Bucket Digging Force: 103 kN Arm Digging Force: 67 kN Max Digging Depth: 5500 mm Max Digging Radius: 8330 mm Max Dumping Height: 6115 mm Gradeability: 70% (35°) Ground Pressure: 43 kPa ## Engine Engine Model: ISUZU 4JJ1X Rated Net Power: 84 kW / 2000 rpm Displacement: 2.999 L Engine Type: 4-stroke, water-cooled, turbocharged ## Hydraulic System Main Pump: Double variable displacement axial piston pump Fuel Tank: 240 L Hydraulic Tank: 150 L Auxiliary Hydraulic Output: 42 L/min
