Sany SY 35 U

# SANY SY35U (English Specs) - Model: SANY SY35U - Operation weight: 3855 kg (Cab version) - Bucket capacity: 0.12 m³ - Max digging depth: 3105 mm - Max digging reach at ground level: 5465 mm - Max dumping height: 3460 mm - Transport dimension: 4915 mm(L) × 1720 mm(W) × 2515 mm(H) - Zero tail swing ### Engine - Engine model: Yanmar 3TNV88F - Rated power: 18.2 kW (24.4 HP) @2200 rpm - Displacement: 1642 cc - Fuel tank: 50 L ### Hydraulic System - Main pump: Variable piston pump, max flow 88 L/min - System pressure: 24.5 MPa - Bucket breakout force: 30.4 kN - Arm breakout force: 18.2 kN ### Travel & Swing - Travel speed: 2.2 / 4.5 km/h - Swing speed: 9 rpm - Track shoe width: 300 mm - Gradeability: 30°
